P10 RGB LED Module High-Bright Waterproof LED Screen Module for Outdoor Billboards | JunChen Display
IP65 Protection 3840Hz Refresh Rate - Durable Outdoor LED Screen Module | JunChen Display
- 10mm pixel pitch: 10,000 dots/㎡ density for clear outdoor visuals (best view distance ≥10m).
- IP65 full waterproof: Resists rain, dust, and moisture for reliable outdoor operation.
- 5000nits high brightness: Anti-glare design adapts to strong sunlight and night use.
- 3840Hz refresh rate: Flicker-free display ensures clear viewing from long distances.
- Anti-UV & durable: 100,000+ hours lifespan with anti-oxidation shell for outdoor longevity.
- Quick splicing: Modular design supports wall-mount/hanging, saving installation time.
5.0
IP Rating:
IP65
Shipping Cost:
:
Contact the supplier about freight and estimated delivery time.
Tube Chip Color:
Full Color
Model NO.:
P6.67 P8 P10
Shipping:
Support Sea freight
Place of Origin:
China
Payments:
L/C,D/A,D/P,T/T,Western Union,MoneyGram,OA
design customization
Please fill out the form below to request a quote or to request more information about us. Please be sure to upload customized requirement documents or pictures, and we will get back to you as soon as possible with a response. we're ready to start working on your new project, contact us now to get started.
Please fill out the form below to request a quote or to request more information about us. please be as detailed as possible in your message, and we will get back to you as soon as possible with a response. we're ready to start working on your new project, contact us now to get started.
Average Power Consumption
350W / m²
Pitch
10mm
Cabinet Size
960X960mmx145mm
Cabinet Material
Metal Cabinet
Package Gross Weight
38.000kg
Package Size
105.00cm * 105.00cm * 20.00cm
Production Capacity
100000pices/Year
HS Code
8528591090
Origin
China
Transport Package
Wooden Case/Flight Case/Carton Box or as Required
Certification
CE, RoHS, CCC, ETL
Display Type
LED Video Display
Scanning Mode
1/2
Pixel Configuration
1R, 1G, 1B
Refresh Rate
1920-3840Hz
Application
Advertising
Specification
960x960X145mm
Pixel Pitch
10mm
Pixel Density
10000 dot / m²
Display Function
Video Display, Image & Text Display, Text Display, Market Display
Color
1r1g1b
Durable, High-Definition, Easy-Maintenance
JunChen Display’s P10 RGB LED Module is a professional outdoor LED screen module tailored for high-demand outdoor scenarios. Equipped with 10mm pixel pitch, IP65 waterproof protection, 5000 nits high brightness, and wide temperature adaptation, it delivers consistent, vivid visuals while withstanding rain, dust, and extreme weather—becoming the reliable core of outdoor display projects.
● Waterproof
● High-Bright
● Durable
● Stable
Product Display
Bright, Durable, Clear, Energy-efficient
P10 Pixel Outdoor Clarity
The p10 rgb led module’s 10mm pixel pitch and 10,000 dots/㎡ density deliver sharp visuals, making this led screen module ideal for large outdoor billboards and ads.
IP65 Full Waterproof Protection
This led screen module features IP65 waterproof shell and sealed connectors, effectively resisting rain, dust, and humidity in outdoor environments like streets and stadiums.
5000nits Sunlight-Resistant Brightness
5000nits high brightness of the p10 rgb led module eliminates glare under strong sunlight, ensuring clear visibility for outdoor audiences day and night.
Modular Quick Installation
The p10 rgb led module’s modular design supports tool-free splicing, enabling fast setup for outdoor display projects—reducing labor and construction costs.
Application Scenario
Outdoor Billboards
Ideal for large-scale outdoor billboards on highways, urban CBDs—p10 rgb led module’s high brightness and clear visuals attract passing traffic.
Street Advertising Screens
Perfect for street-side vertical advertising screens—led screen module’s IP65 protection adapts to daily wind and rain, ensuring 24/7 operation.
Stadium Perimeter Displays
Suitable for stadium perimeter advertising rings—modular splicing of p10 rgb led module fits curved or linear structures, delivering dynamic visuals.
Public Information Displays
Applied to outdoor public information screens (stations, scenic spots)—led screen module’s stability and durability meet long-term public service display needs.
FAQ
1
What’s the viewing distance of JunChen’s p10 rgb led module?
Recommended viewing distance is ≥10m, suitable for medium-to-large outdoor spaces like highways and plazas.
2
Can the led screen module withstand heavy rain and strong sunlight?
Yes, it has IP65 full waterproof protection and 1000 nits anti-glare brightness, adapting to outdoor harsh weather.
3
How to install the p10 rgb led module for outdoor displays?
It supports tool-free splicing with standardized size, compatible with wall-mount/column-mount—no professional skills required for basic installation.
4
What’s the lifespan and warranty of this led screen module?
100,000+ hours lifespan with a 3-year warranty, covering manufacturing defects and outdoor use-related issues.
5
Can the p10 rgb led module be spliced into curved outdoor screens?
Yes, its modular design supports slight curved splicing (≤15°), fitting stadium perimeters or curved building facades.
6
Is the p10 rgb led module energy-efficient for 24/7 outdoor operation?
Yes, it adopts low-power LED chips, reducing energy consumption by 25% vs. ordinary modules—ideal for 24/7 outdoor advertising use.
